Home EV Chargers

Home EV Chargers




We have a wide range of smart EV charging stations for home use. Our stations are intuitive and easy to use. Their assembly, as well as the process of loading the vehicle itself, run smoothly and efficiently.

With home EV charging station, you can charge your car whenever you want, and by using the night energy tariff you can save a lot.

We offer charging stations for electric cars in various equipment variants - with a type-2 socket or a charging cable. In addition, the chargers are equipped with an RFID authorization function, a mobile application and the necessary security.

Smart Mini Wallbox

Smart Mini Wallbox






Smart Mini Wallbox by Teison is a smart and compact electric vehicle charging station with a compact size and stylish design. Easy control via the dedicated TeisonMe mobile app makes the Smart Mini Wallbox the most reliable and safe home charger. The charging station is equipped with a 4-meter charging cable and the most popular among electric vehicles type-2 connector.


COMPACT
Minimalist and compact design.
INTELLIGENT
Control via mobile app.
Plug&Play function.
SAFE
IP65 protection degree. AC+DC protection.
FAST CHARGING
Maximum charging power up to 22kW.
CLOUD-BASED DATA
Possibility of remote control.




The Smart Mini Wallbox can be controlled by the TeisonMe mobile app, which allows you to:
  • remotely start and stop charging,
  • setting charging parameters,
  • monitoring charging status,
  • scheduling charging,
  • collecting data on operations;

Smart Mini Wallbox has Plug & Play mode, with which the EV charging process starts automatically as soon as the charger is connected to the car, without the need for setup.





Smart Mini Wallbox is made of strong materials that guarantee resistance to the elements. As a result, it can be safely installed both indoors and outdoors.


ORDER NOW!

Smart Mini Wallbox charging station is very safe to use. It meets the EN 61851-1 safety standard, protects internal components from harmful external conditions and detects AC + DC faults. In addition, the charger is certified by TÜV SÜD.





POSSIBLE INSTALLATION LOCATIONS

  • PRIVATE HOUSES

  • PARKING LOTS

  • COMPANIES AND HOTELS

  • CAR DEALERS

  • CAR REPAIR SHOPS

  • SHOPPING CENTRES


TECHNICAL DATA
Charging current 16/32A
Frequency 50/60Hz
Charging power 7kW/ 11kW/ 22kW
Operating temperature  -30° to +60°C
Humidity max. 95% RH
Enclosure rating IP65 / IK08
Dimensions 225 x 225 x 100mm
Weight

+/- 5kg

Charging connector 4m cable+type-2 connector
Installation method wall mounted/dedicated pedestal (optional)

Wallbox Home Pro

Wallbox Home Pro






Wallbox Home Pro by Teison is an electric vehicle charging station that has been designed for convenient charging of vehicles, mainly on private properties. Available in two equipment variants: with an integrated 5-metre cable or type-2 socket, the charging station features a colour LCD display and RFID card reader.


USER-FRIENDLY INTERFACE
Intuitive operation guaranteed
LCD DISPLAY
Colour display indicates charging status in real time.
RFID AUTHENTICATION
Start and stop charging by means of RFID card.
ROBUST DESIGN
IP65 protection confirms the robustness of the device.
HIGH USER SAFETY
The Wallbox Home Pro has all the necessary electrical safety features and a safety button to stop charging with a single click.

ORDER NOW




Wallbox Home Pro charging station has a built-in RFID card reader so that the station can only be used by authorised persons.


RFID authorisation function is particularly useful in public car parks or commercial premises such as hotels, shopping centres or restaurants.

Each Wallbox Home Pro is equipped with 5 RFID cards.



With bulit-in screen you can track the current charging status of the car and parameters such as voltage, charging current, amount of energy used, and vehicle charging time.


Charging station is made of a solid materials that guarantee resistance to external factors. It can be safely installed both inside and outside buildings.


ORDER NOW





Possible installation locations:

  • PRIVATE PROPERTIES

  • GARAGES

  • FIRMS AND HOTELS

  • CAR SHOWROOMS

  • CAR WORKSHOPS

  • SHOPPING CENTERS


TECHNICAL DATA
Prąd ładowania 16/32A
Frequency 50/60Hz
Charging power 7kW/ 11kW/ 22kW
Working temperature from -30° to +50°C
Humidity max. 95% RH
Enclosure rating IP65 / IK08
Dimensions 398 x 324 x 120mm
Weight

+/- 8kg

Charging connector 4,5m cable + socket type-2
Installation wallmounted / on dedicated pedestal (optional)

Wallbox JNT-EVC10

Wallbox JNT-EVC10






JNT-EVC10 series charging stations are the best choice for people who value high quality, modern and unique design, as well as functionality and ease of use.

Depending on the individual needs and preferences of the User, we offer two variants of station equipment: with a socket or a charging cable. Both versions are compatible with the Type-2 connector, the most popular among electric vehicles.


FRIENDLY INTERFACE

EVC10 stations have a friendly interface that ensures intuitive and simple operation.
INTELIGENT
Control via a mobile application. Plug & Play.
SAFE
Protection degree IP65. AC + DC protection. Emergency stop button.





On the 4.3 ″ screen you can keep track of the VEHICLE charging status.

JNT-EVC10 wallbox has an RFID card reader, so only authorized persons with their own cards that starts the charging process can use the charger. The RFID authorization function is especially useful in public parking lots or in commercial facilities, such as hotels or restaurants.


ORDER NOW

Solid structure and material from which the charging stations are made, as well as the method of their installation, guarantee a high level of safety during the charging process of electric vehicles, both in outdoor conditions and in closed facilities.





POSSIBLE INSTALLATION LOCATIONS

  • PRIVATE PROPERTIES

  • GARAGE

  • FIRMS AND HOTELS

  • CAR SHOWROOMS

  • CAR WORKSHOPS

  • SHOPPING CENTERS


TECHNICAL DATA
TECHNICAL DATA JNT-EVC10 3.6kW JNT-EVC10 7kW JNT-EVC10 11kW JNT-EVC10  22kW
Rated voltage 230V AC ± 10% 230V AC ± 10% 400V AC ± 10% 400V AC ± 10%
Max input current 16A / 1-faza 32A / 1-faza 16A / 3-fazy 32A / 3-fazy
Max output power 3.6kW 7kW 11kW 22kW
Frequency 50/60 Hz
Residual current protection typ A + DC 6mA
Charging connector 5m cable + type2-2 socket / type-2
RFID authorisation yes (+ 2 cards)
LED lights LED lights
Installation wall mounted/dedicated pedestal
Safety degree IEC 61851-1 , IEC 61851-21-2
Warranty 2 years
IP degree IP65 <witha cable> / IP54 <with socket>, IK08
Protection over / undervoltage protection, overvoltage protection, overheating protection, overcurrent protection, short circuit protection
Working temperature -30 ℃ ~ +50℃
Storage  temperature -40 ℃ ~ +70℃
Max humidity 5%~95%,
Dimensions 350*250*130mm
Weight ~6,5kg

Wallbox JNT-EVC11

Wallbox JNT-EVC11






The JNT-EVC11 series charging station features a modern, minimalist design, as well as easy operation. It has a built-in 5m vehicle charging cable.

Depending on the user's individual needs and preferences, the station can be equipped with an RFID card reader.


MINIMALISTIC INTERFACE

JNT-EVC11 stations have a simple and user-friendly interface.

MOBILE APP
The charging station can be controlled via the HOME EV mobile app.

SAFETY
IP65 degree of protection. AC+DC protection. Emergency stop button.





JNT-EVC10 charging station can be controlled by a mobile application HomeEV, która allows to:
  • remote start and stop of vehicle charging,
  • setting charging parameters,
  • charging status monitoring,
  • scheduling of charging time,
  • collecting data on performed operations;

You can set the mode  Plug & Play, thanks to which the charging process of electric vehicles starts automatically after connecting the charger to the car, without the need for tedious configuration.




Wallbox JNT-EVC11 has an RFID card reader (optional), so that only authorized persons with their own card that starts the charging process can use the charger. The RFID authorization function is especially useful in public parking lots or in commercial facilities, such as hotels or restaurants..


ORDER NOW

The solid structure and the material from which the charging stations are made, as well as the method of their installation, guarantee a high level of safety during the charging process of electric vehicles, both outdoors and indoors.





POSSIBLE INSTALLATION LOCATIONS

  • PRIVATE PROPERTIES

  • GARAGES

  • FIRMS AND HOTELS

  • CAR SHOWS

  • CAR WORKSHOPS

  • SHOPPING CENTERS

TECHNICAL DATA JNT-EVC11 3.6kW JNT-EVC11 7kW JNT-EVC11 11kW JNT-EVC11 22kW
Rated voltage 230V AC ± 10% 230V AC ± 10% 400V AC ± 10% 400V AC ± 10%
Output current 16A / 1-phase 32A / 1-phase 16A / 3-phase 32A / 3-phase
Maximum output power 3.6kW 7kW 11kW 22kW
Frequency 50/60 Hz
Residual current protection typ A + DC 6mA
Charging connector 5m cabel + socket type-2
Light indicators LED light
Installation method wall mounted/ dedicated stand
Security standard IEC 61851-1 , IEC 61851-21-2
Guarantee 2 years
Level of security IP65, IK08
Security over / undervoltage protection, overvoltage protection, overheating protection, overcurrent protection, short circuit protection
Working temperature -30 ℃ ~ +50℃
Storage temperature -40 ℃ ~ +70℃
Maximum humidity 5%~95%
Communication Bluetooth
HomeEV app (iOS, Android) remote starting and stopping the vehicle charging, setting charging parameters, planning the charging time, viewing the charging status, setting charging modes, collecting data on performed operations
Dimensions 360*250*100mm
Weight 5kg

Wallbox MaxiCharger

Wallbox MaxiCharger






Wallbox MaxiCharger form Autel is a smart, safe and extremely stylish charging station for electric vehicles. It has a built-in type-2 vehicle charging cable, a dedicated mobile application, an RFID card reader and supports the OCPP1.6 communication protocol.


SMART
Control via mobile application.

SAFE
Degree of protection IP65. AC+DC protection.

FAST
Maximum charging power up to 22kW.

GREAT DESIGN
The project was awarded in the world's largest design competition Red Dot Design.

OCPP1.6 PROTOCOL
Compliant with the OCPP1.6 protocol for commercial applications.




The Wallbox MaxiCharger charging station can be controlled by the MaxiCharger mobile application, which allows you to:
  • start and stop charging the vehicle remotely,
  • setting loading parameters,
  • charging status monitoring,
  • charging time scheduling,
  • collecting data on performed operations,
  • vehicle battery status tracking;




The MaxiCharger charging station is highly secure. Built-in protections prevent irregularities in the flow of electricity and unwanted failures. Real-time data analysis allows for a quick response to any safety alerts.


ORDER NOW





POSSIBLE INSTALLATION PLACES

  • PRIVATE HOUSES

  • GARAGES

  • COMPANIES AND HOTELS

  • SHOW ROOMS

  • CAR RENTALS

  • SHOPPING CENTERS


TECHNICAL DATA Wallbox MaxiCharger 7.4kW Wallbox MaxiCharger 11kW Wallbox MaxiCharger 22kW
Nominal voltage 230V AC ± 15% 400V AC ± 15% 400 AC ± 15%
Output current 32A 16A 32A
Maximum output power 7.4kW / 1-phase 11kW /3-phases 22kW / 3-phases
Frequency 50hz
RFID authorization Yes
Residual current protection AC 30mA, DC 6mA
Charging connector 5m cable+ type-2 socket
Indicator light LED Light
Installation on the wall
